SCALE  (Up / Up&Down Scaler)

• Specification & Performance
  - Input Resolution
    ◦ Min Input Resolution : 720 x 1280
  - Output Resolution
    ◦ Up to QHD
  - 4-BUS of Interface, 3 Line Memory
  - 8 bit / 10 bit of Bit-Processing
  - Scaling Ratio
    ◦ Up Scale : x 4.0
  - Supports Command and Video Mode
  - Uses Bi-Linear Interpolation

BSCALE  (Up & Down Scaling IP)

• Specification & Performance
  - Input Resolution
    ◦ Min Input Resolution : 800 x 400
    ◦ Max Input Resolution : 3840 x 2160
  - Output Resolution
    ◦ Up to 8K
  - 4-BUS of Interface, 4 Line Memory
  - 8 bit / 10 bit of Bit-Processing
  - Scaling Ratio
    ◦ Up Scale : x 4.0
    ◦ Down Scale : x 0.5
  - Uses Polynomial Interpolation (3rd order)
  - Sharpness Control
  - Low pass Filter Control (Down Scale Only)
